DIMENSIONS |
 |
 |
U.S. UNITS |
 |
Length |
 |
 |
93.7 in. |
 |
 |
 |
Seat Height |
 |
 |
 |
 |
 |
 |
Laden  |
 |
 |
30.0 in. |
 |
 |
 |
Unladen |
 |
 |
31.0 in. |
 |
 |
 |
Ground Clearance |
 |
 |
6.7 in. |
 |
 |
 |
Rake Steering Head/Trail |
 |
 |
30.0º / 4.3 in. |
 |
 |
 |
Wheelbase |
 |
 |
66.8 in. |
 |
 |
 |
Fuel Capacity  |
 |
 |
5.0 gals. |
 |
 |
 |
Oil Capacity |
 |
 |
4.5 qts. |
 |
 |
 |
Weight |
 |
 |
 |
 |
 |
 |
Dry
Weight |
 |
 |
618.0 lbs. |
 |
 |
 |
Running
Order |
 |
 |
655.0 lbs. |
 |
 |
 |
POWERTRAIN |
 |
 |
|
 |
Engine  |
 |
 |
Revolution® |
 |
 |
 |
Displacement |
 |
 |
69.0 in.³ |
 |
 |
 |
Bore x Stroke |
 |
 |
3.94 in. x 2.84 in. |
 |
 |
 |
Engine Torque    |
 |
 |
80.0 ft. lbs. @ 7000 rpm |
 |
 |
 |
Fuel System  |
 |
 |
Electronic Sequential Port Fuel Injection (ESPFI) |
 |
 |
 |
Compression Ratio |
 |
 |
11.3:1 |
 |
 |
 |
Miles per Gallon  |
 |
 |
 |
 |
 |
 |
Carb. |
 |
 |
N/A |
 |
 |
 |
ESPFI |
 |
 |
47 hwy / 37 city |
 |
 |
 |
Primary Drive |
 |
 |
Gear |
 |
 |
 |
Gear Ratio (overall) |
 |
 |
 |
 |
 |
 |
1st |
 |
 |
11.752 |
 |
 |
 |
2nd |
 |
 |
7.898 |
 |
 |
 |
3rd |
 |
 |
6.322 |
 |
 |
 |
4th |
 |
 |
5.459 |
 |
 |
 |
5th |
 |
 |
4.889 |
 |
 |
 |
6th |
 |
 |
N/A |
 |
 |
 |
WHEELS/TIRES |
 |
 |
|
 |
Wheels  |
 |
 |
 |
 |
 |
 |
Front |
 |
 |
Staggered 10-spoke cast aluminum |
 |
 |
 |
Rear |
 |
 |
Staggered 10-spoke cast aluminum |
 |
 |
 |
Tire Size |
 |
 |
 |
 |
 |
 |
Front |
 |
 |
120/70ZR19 60W |
 |
 |
 |
Rear |
 |
 |
180/55ZR18 74W |
 |
 |
 |
ELECTRICAL |
 |
 |
|
 |
 |
 |
Instruments |
 |
 |
Electronic speedometer; odometer; dual resettable tripmeter; diagnostic
readout; tachometer; digital clock |
 |
 |
 |
Indicator Lamps |
 |
 |
High beam; neutral; low oil pressure; turn signals; engine diagnostics;
security system (optional); coolant temperature; low fuel |
 |
 |
 |
CHASSIS |
 |
 |
|
 |
Brakes |
 |
 |
 |
 |
 |
 |
Front |
 |
 |
Dual |
 |
 |
 |
Rear |
 |
 |
Single |
 |
 |
 |
Lean Angle (per SAEJ1168) |
 |
 |
40º / 40º |
 |
 |
 |
Exhaust System |
 |
 |
Chrome, straight-shot dual pipes |
 |
 |
 |
COLOR OPTIONS  |
 |
Vivid black, black cherry, rich sunglo blue, yellow pearl, brandy wine
sunglo, mirage orange  |
|
 |
OPTIONAL EQUIPMENT |
 |
Security system  |
|
 |
UNIQUE FEATURES |
 |
Inverted front fork; two-tone silver and black engine; high-mounted
stylized rear fender; stylized, forged, aluminum triple clamps; forward
mounted ignition switch; Brembo® 4-piston brake calipers; mid-mount
controls  |
|
 |
PRICING  |
 |
MSRP |
|
 |
 |
Vivid
black |
$15,495 |
 |
 |
Color |
$15,740 |
 |
 |
Two-tone |
N/A |
 |
 |
Custom
color |
N/A |
 |
 |
Anodized |
N/A |
 |
 |
Wheel Option |
N/A |
 |
 |
Chrome Engine Covers Option |
N/A |
 |
 |
H-D® Factory Security System |
$275 |
 |
 |
ESPFI |
Standard |
 |
 |
California Emissions |
|
 |
 |
Carb. |
N/A |
 |
 |
ESPFI |
$100 |
 |
 |
Freight (applies to the 48 contiguous states and Alaska only) |
$285 |
 |
|
