DIMENSIONS |
|
|
U.S. UNITS |
|
Length |
|
|
90.1 in. |
|
|
Seat Height |
|
|
|
|
|
Laden(1) |
|
|
26.0 in. |
|
|
Unladen |
|
|
N/A |
|
|
Ground Clearance |
|
|
4.4 in. |
|
|
Rake Steering Head/Trail |
|
|
29.6� / 4.6 in. |
|
|
Wheelbase |
|
|
60.0 in. |
|
|
Fuel Capacity(2) |
|
|
3.3 gals. |
|
|
Oil Capacity |
|
|
3.6 qts. |
|
|
Weight |
|
|
|
|
|
Dry
Weight |
|
|
553.0 lbs. |
|
|
Running
Order |
|
|
N/A |
|
|
POWERTRAIN |
|
|
|
|
Engine(3) |
|
|
Evolution� |
|
|
Displacement |
|
|
53.86 in.� |
|
|
Bore x Stroke |
|
|
3.00 in. x 3.81 in. |
|
|
Engine Torque(4)(5) |
|
|
51.0 ft. lbs. @ 4300 rpm |
|
|
Fuel System(6) |
|
|
Carburetor |
|
|
Compression Ratio |
|
|
8.9:1 |
|
|
Miles per Gallon(7) |
|
|
|
|
|
Carb. |
|
|
57 hwy / 48 city |
|
|
ESPFI |
|
|
N/A |
|
|
Primary Drive |
|
|
Chain |
|
|
Gear Ratio (overall) |
|
|
|
|
|
1st |
|
|
10.944 |
|
|
2nd |
|
|
7.524 |
|
|
3rd |
|
|
5.834 |
|
|
4th |
|
|
4.806 |
|
|
5th |
|
|
4.071 |
|
|
WHEELS/TIRES |
|
|
|
|
Wheels(8) |
|
|
|
|
|
Front |
|
|
Silver 13 spoke cast aluminum alloy |
|
|
Rear |
|
|
Silver 13 spoke cast aluminum alloy |
|
|
Tire Size |
|
|
|
|
|
Front |
|
|
100/90-19 57H |
|
|
Rear |
|
|
150/80B16 71H |
|
|
ELECTRICAL |
|
|
|
|
Electronics |
|
|
Optional security system |
|
|
Instruments |
|
|
Electronic speedometer; odometer; resettable tripmeter; diagnostic readout |
|
|
Indicator Lamps |
|
|
Oil pressure; engine diagnostics |
|
|
CHASSIS |
|
|
|
|
Brakes (diameter x width) |
|
|
|
|
|
Front |
|
|
11.5 in. x 0.20 in. |
|
|
Rear |
|
|
11.5 in. x 0.23 in. |
|
|
Lean Angle (per SAEJ1168) |
|
|
30� / 31� |
|
|
Exhaust System |
|
|
Staggered shorty duals |
|
|
COLOR OPTIONS(9) |
|
Vivid black, brilliant silver pearl, sierra red pearl, chopper blue
pearl
|
|
|
UNIQUE FEATURES |
|
Wide polished handlebar; lowered front and rear suspension; low solo
seat; new fuel tank graphics
|
|
|
PRICING(10) |
|
MSRP |
|
|
|
Vivid
black |
$6,895 |
|
|
Pearl
or Sunglo |
$7,115 |
|
|
Two-tone |
N/A |
|
|
Anodized |
N/A |
|
|
Wheel option |
$320 (laced) |
|
|
H-D� factory security system |
$275 |
|
|
ESPFI |
N/A |
|
|
California emissions |
|
|
|
Carb. |
$120 |
|
|
ESPFI |
N/A |
|
|
Freight (applies to the 48 contiguous states and Alaska only) |
$195 |
|
